| Dimensions | Unfolded, propellers and landing gears included, 883×886×398 mm
Folded, propellers and landing gears
excluded, 722×247×242 mm |
|---|
| Diagonal Wheelbase | 643 mm |
|---|
| Weight | Approx. 4.69 kg (with two TB55 batteries) |
|---|
| Max Takeoff Weight | 6.14 kg |
|---|
| Max Payload | 1.45 kg |
|---|
| Operating Frequency | 2.4000-2.4835 GHz; 5.725-5.850 GHz |
|---|
| EIRP | 2.4 GHz: ≤ 26 dBm (NCC/FCC); ≤ 20 dBm (CE/MIC); ≤ 20 dBm (SRRC)
5.8 GHz: ≤ 26 dBm (NCC/FCC); ≤ 14
dBm (CE); ≤ 26 dBm (SRRC) |
|---|
| Hovering Accuracy (P-mode with GPS) | Vertical:±1.64 feet (±0.5 m) or ±0.33 feet
(±0.1 m, Downward Vision System enabled)
Horizontal:±4.92
feet (±1.5 m) or ±0.98 feet (±0.3 m, Downward Vision System enabled) |
|---|
| Max Angular Velocity | Pitch: 300°/s, Yaw: 120°/s |
|---|
| Max Pitch Angle | S-mode: 35°;
P-mode: 30° (Forward Vision System enabled: 25°);
A-mode: 30° |
|---|
| Max Ascent Speed | 16.4 ft/s (5 m/s) |
|---|
| Max Descent Speed (vertical) | 9.8 ft/s (3 m/s) |
|---|
| Max Speed | S-mode/A-mode 81 kph (50.3 mph);
P-mode: 61.2 kph (38 mph) |
|---|
| Max Service Ceiling Above Sea Level | 9842 feet (3000 m, with 1760S propellers) |
|---|
| Max Wind Resistance | 39.4 ft/s (12 m/s) |
|---|
| Max Flight Time (with two TB55 batteries) | 38 min (no payload),
24 min (takeoff weight: 6.14 kg) |
|---|
| Supported DJI Gimbals | Zenmuse X4S/X5S/X7/XT/XT2/Z30 |
|---|
| Supported Gimbal Mounting | Single Gimbal, Downward |
|---|
| Ingress Protection Rating | IP43 |
|---|
| GNSS | GPS+GLONASS |
|---|
| Operating Temperature | -4° to 122° F (-20° to 50° C) |
|---|
